Hardware installation and packaging specifications:

Model: LB1

Brand Name: OEM

Motherboard Compatibility: ATX/M-ATX

Expansion slot: PCIE*7

Panel interface: HD Audio;USB3.0*1;USB2.0*2

Hard disk position: 3.5''HDD*1;2.5''SSD*1

Radiator height limit: 165MM

Graphics card length limit: 305MM

Fan position: front 12CM*3;

Top 12CM*2;

Rear 12CM*1;

12CM*2 on the top of the power compartment

Product material: PCC blackened steel plate + tempered glass

Plate thickness: 0.5mm

Power support: bottom ATX power supply

Chassis size: L378*W190*H447MM (including foot pads)

Hardware size: L335*W190*H435MM

Packing size: L500*W245*H445MM

Loading standard: 40HQ=1240pcs
