Hardware installation：

1. Standard ATX power supply/bottom power supply

2. One 12CM fan can be installed on the rear panel

3. Hard disk 3.5*2+2.5*2

4. Expansion PCI socket*7

5. MicroATX / MIniATX / ATX motherboard can be installed

6. The length of the graphics card is 320MM

7. CPU height 150MM

8. Front panel 360 water drain or three 12CM fans

9. Two 12CM fans at the top

10. USB1.0*1+3.0 imitation*1+AUDIO

Product material specifications and loading standards:

1. Hardware structure: 0.45SPCC full paint

2. Hardware specifications: 330*190*425MM

3. Product specifications: (including panel) 370*190*435MM

4. Packaging specification: 500*250*435mm

5. Weight: net weight: 4.3KG gross weight: 5KG

6. Loading standard: 40HQ=1250PCS
